GE DS200TCPAG1A Overspeed Tachometer Module

GE DS200TCPAG1A Overspeed Tachometer Module

GE DS200TCPAG1A Overspeed Tachometer Module

The J3 motor connector on the 6410 mates to a 5-pin PCD screw cable connector. The mating cable connector is type ELVP05100. Cable requirements The mating connector terminals will accept #16 to #28 AWG wire. However, use #16 AWG or heavier for motor phase excitations. For the motor cable, use cable with two twisted pairs twisted at about 3 to 4 turns per inch (1 to 1.5 turns per centimeter) for the motor phase excitations and a fifth wire for the case ground. As an option, the cable may be shielded to reduce radiated noise. A single shield can be used around both phase excitations and the ground wire or each phase excitation (twisted pair) can be individually shielded as in the Pacific Scientific cables. Connect shields to pin 5 of the mating connector.

Procedure

1. Strip the wires to 0.27 in (7mm).

2. Attach wires to connector as indicated in the diagram. Note: Make sure the screws on the PCD connector are tightened down firmly on the wiring. Caution Do not solder the tips of the cables before insertion into the connector. Solder can contract and cause a loose connection over time
