GE DS3820PS3A Remote control module

1  From the main power measurement screen select “menu” and enter. Now select "tune" and enter.

2. Set the percentage range of the power scale to be displayed by repeatedly pressing the ±50% key.

3. Now select the horizontal sweep time you desire by selecting “graph” and choosing the time scale.

4. You may now use the screen to tune the laser power. See Section 4.4.2.3. for full details. 5. Press “power” to exit to the main measurement screen.

To use the Nova II to measure Laser energy:

1. Verify that the display shows "energy" in the upper right hand side of the display.

2. If the display shows "power" and units of W, mW etc. then press "energy" to switch to the energy measurement mode.

3. The energy mode is manual ranging. Select "range", enter then use the navigation keys to select the proper range. Press save if you want this range to be the startup default. The correct range is the lowest one that is larger than the pulse energy measured. Note that the range will be displayed in the lower right corner of the main display.
