GE IS200TBAIH1A Remote control module

GE IS200TBAIH1A Remote control module

The GE IS200TBAIH1A is a type of input module for the GE Fanuc VersaMax series of programmable logic controllers (PLCs). This module is designed to provide high-speed counter inputs to the PLC system. It has a total of four input channels, each of which is capable of counting pulses at a maximum frequency of 20 kHz. The module can be configured to count either up or down, and it also has a programmable latch function that can be used to capture the current count value. The module communicates with the PLC through a standard backplane interface, and it can be hot-swapped with other modules in the system for easy maintenance and upgrades.

IS200TBAIH1A is an analog input card developed by General Electric (GE) and is a component of the Speedtronic Mark series. These systems are used to manage and automate the operation of industrial gas and steam turbines. IS200TBAIH1A is a long printed circuit board with various electronic components. The largest component is two long black terminal blocks fixed at the left edge. These terminal boards are identified as TB1 and TB2. Both terminal boards can contain up to twelve (12) silver metal terminals that look like cubes. There are three (3) long jack connector ports on the other side of IS200TBAIH1A. Each connector port has thirty-seven (37) small female connectors that can be used to connect additional components or circuit boards to IS200TBAIH1A. The connectors are labeled JT1, JS1, and JR1. The center of IS200TBAIH1A is occupied by various components. There are at least ten (10) transistors on IS200TBAIH1A, most of which are arranged in the middle. Ten (10) variable resistors or potentiometers are also aligned along the center of IS200TBAIH1A.
