RELIANCE ELECTRIC S-D4041 Overspeed detection module

There are 12 general purpose inputs on the auxiliary connector. The inputs are configured as two groups of six. Each group can be configured as sourcing or sinking. Connect the DCSS pin to +24 V for a sourcing configuration. Connect the DCSS pin to COM for a sinking configuration. You can use the internal +24 V supply. See Figure 19 below. The 12 inputs are available on the four axis MMC. The two axis MMC has six inputs. See the pinouts on pages 39 and 40 for those connections.

Diagnostic Error Codes

While the MMC is running, the DIAG LED on the CPU module will flash a three digit code signal if there is an error. For example, if there is a long pause-flashpause-flash-flash-pause-flash-flash-flash-long pause, the code is 123. The errors are described below.
