GE IS200VSCAH2A Digital input module

it is not possible to configure or program the OC950 with a dumb terminal). Two communication links are available, RS-232 and RS-485. RS-485 allows a single computer to communicate with up to 32 SC950's in multi-axis configurations. A DIPswitch on the OC950 selects the communications address for RS-485 communication. The 950IDE defaults to communicate with axis 255 upon start up

The T10 terminal is a Burr-Brown TM2500.

1 Solder the cable leads to the SC950 mating connector and the T10 connector as shown.

2. Assemble the connector housings.

3. Plug the connectors into the SC950 and T10 and affix the connectors to the units.
