1797-PS2E2/A Output module

Motor Feedback Configuration The S200 Base Unit drives only support SFD motor feedback. If you are using SFD motor feedback, no further configuration is needed. If you want to use SinCos or ComCoder as motor feedback, you must use the AUX FB (J14) connector, which is not available on Base Unit drives. 4.1.5 Save Options There are three types of Save options. It is important to know how to use each type to ensure that configurations are not lost. • Download NV – This button will save the parameter settings displayed in S200 Tools to the selected drive. These parameters are saved to the drive's permanent memory and are recalled during a power-up cycle. • Download Drive – This button will save the parameter settings displayed in S200 Tools to the selected drive/node. However, unlike Download NV, these parameters are only saved to the drive's temporary RAM and will not be recalled at a power-up cycle. It is recommended that you use the Download Drive button when testing settings. Once you are satisfied with the settings, click the Download NV button to permanently save the settings to the drive. • Save/Save As – You can also save the settings of a drive as a configuration file (*.S2C). Remember, saving a configuration file does NOT save the settings to the drive. Configuration files can be helpful for saving multiple drive setups. You can easily download a setting to a drive by opening the configuration file in the Offline mode and clicking the Download NV/Drive buttons once the proper drive is selected in the Online mode. It is recommended that you save a configuration file for each setup.

S200 SYNQNET DRIVE

 Follow the instructions below if you are using one of the following S200 Series Drives: • S20250-SRS, S20260-SRS, S20350-SRS, S20360-SRS, S20330-SRS, S20630-SRS, S20250-SDS, S20260-SDS, S20350-SDS, S20360-SDS, S20330-SDS, S20630-SDS The setup consists of the following steps: 1. MDK and SynqNet Controller Installation 2. S200 Tools Software Installation 3. Hardware Setup 4. S200 Tools Communication Wizard 5. SynqNet Configuration 6. Motor Feedback Configuration 7. Save Options 4.2.1 MDK and SynqNet Controller Installation Before you can use an S200-SynqNet Drive, you must first install the Motion Developer's Kit Software package and SynqNet controller from Motion Engineering Inc. For more information about installation, please see MEI's Technical Support website.S200 Tools Software Installation Follow the installation instructions from the CD-ROM or zip file. See S200 Tools Software Installation Guide. S200 Tools supports the following Operating Systems: • Windows 2003 Server • Windows XP, All Service Packs - (SP) • Windows 2000, SP2 • Windows XP embedded • Windows NT4, SP6 4.2.3 Hardware Setup 4.2.3.1. DRIVE SETUP NOTE: The drive serial port (J5) is disabled on SynqNet drives. If you are using an S200 SynqNet Drive, you need to establish SynqNet communication link between the S200 SynqNet Drive and the SynqNet motion controller. 1. Plug one end of an Ethernet communications cable to J11 (SynqNet IN) of the S200 drive and the other end to the SynqNet controller's OUT port. 2. One Drive/Node Use another Ethernet communications cable to connect J12 (SynqNet OUT) of the S200 drive to the XMP-SynqNet controller's SynqNet IN port.
