GE IS230SNCIH2A Digital I/O card

Multi-Channel I-Variables Several multi-channel I-variables must be set up for proper operation of the Acc-24E2 in a Turbo PMAC system. The most important are: I7m07: Servo IC m Phase/Servo Clock Direction This variable should be set to 0 on the Acc-24E2A generating the clocks (E13 set 2-3) and set to 3 for the Acc-24C2As to receive the clocks (E13 set 1-2).

I7m00: Servo IC m MaxPhase/PWM Frequency Control

Typically, this will be set to the same value as the variable that controls the system clocks: I7200 on a UMAC Turbo PMAC2, or I6800 on a Turbo PMAC2 Ultralite. If a different PWM frequency is desired then the following constraint should be observed in setting this variable Even though the IC is receiving an external phase clock (see I7m07, above), usually it is best to create the same internal phase clock frequency in the Servo IC.
