GE DS200TCPSG1ARE Speed module

The flag capture registers must also be set up at the MACRO Station for proper homing, encoder capturing, and setting compare outputs. MI911 determines which encoder input the position compare circuitry for the machine interface channel mapped to the specified node uses. MSn,MI911=0 Use channel n encoder counter for position compare function

When MI911 is set to 0

 the channel’s position compare register is tied to the channel’s own encoder counter, and the position compare signal appears only on the EQUn output. When MI911 is set to 1, the channel’s position compare register is tied to the first encoder counter on the ASIC (Encoder 1 for channels 1-4, Encoder 5 for channels 5-8, or Encoder 9 for channels 9-10) and the position compare signal appears both on EQUn and combined into the EQU output for the first channel on the IC (EQU1 or EQU5); executed as a logical OR.
