GE DS200TCQBG1BCA Overspeed detection module

MI911 for the first channel on an ASIC performs no effective function, so is always 1. It cannot be set to 0. MI912 determines which signal or combination of signals, and which polarity, triggers a position capture of the counter for the encoder mapped to the specified node. If a flag input (home, limit, or user) is used, MI913 for the node determines which flag. Proper setup of this variable is essential for a successful home search, which depends on the position-capture function. The following settings may be used: 0: Capture under software control (armed)

The trigger is armed

when the position capture register is read. After this, as soon as the Compact MACRO Station sees that the specified input lines are in the specified states, the trigger will occur — it is level-trigger, not edge-triggered. MI913 parameter determines which of the Flag inputs will be used for position capture (if one is used, see MI912): 0: HMFLn (Home Flag n) 1: PLIMn (Positive End Limit Flag n) 2: MLIMn (Negative End Limit Flag n) 3: USERn (User Flag n) Typically, this parameter is set to 0 or 3, because in actual use the LIMn flags create other effects that usually interfere with what is trying to be accomplished by the position capture. To capture on the LIMn flags, disable their normal functions with Ix25, or use a channel n where none of the flags is used for the normal axis functions.
