GE IS200ATBAG1BAA1 Sensor module

When the Acc-24E2A is used for MLDT feedback in a UMAC Turbo system, a few I-variables must be set up properly. Hardware Setup I-Variables for Servo IC m I7m03 (PFM Clock Frequency): In almost all cases, the clock frequency driving the pulse-generation circuitry for all channels on Servo IC m can be left at its default value of 9.83 MHz (0.102 µsec). I7m03 also controls other clock signals, has a default value of 2258 and rarely needs to be changed.

I7m04 (PFM Pulse Width):

The pulse width, set by I7m04 in units of PFM clock cycles must be set long enough for the MLDT to see, and long enough to contain the rising edge of the RPM start echo pulse, or the rising edge of the single DPM echo pulse. For example, if this edge can come up to 2 µsec after the start of the excitation pulse, and the PMAC clock cycle is at its default of about 0.1 µsec, then I7m04 must be set at least to 20.
