GE IS210AEAAH1B Axial displacement module

Pulse Output Frequency The pulse-output frequency is established by assigning an M-variable to the C sub-channel command register, and writing a value to that M-variable after every power-up/reset. The suggested M-variable for the Motor xx using this register is: Mxx07->Y:{address},8,16,S

Mxx07 for Acc-24E2A MLDT Pulse-Output Registers

The frequency of the pulse output should produce a period just slightly longer than the longest expected response time for the echo pulse. For MLDTs, the response time is approximately 0.35 µsec/mm (9 µsec/inch). On an MLDT 1500 mm (~60 in) long, the longest response time is approximately 540 µsec; a recommended period between pulse outputs for this device is 600 µsec, for a frequency of 1667 Hz. To produce the desired pulse output frequency, the following formula can be used
