FOXBORO P0911VJ Switch

Within each system, each subsystem is single-point grounded. Each of the system ground points is then connected to a tree ground bus with a single insulated conductor (usually yellow). (c) The single-point establishes a signal reference plane in each unit or piece of equipment, and these individual reference planes are connected together and to the earth electrode subsystem. An important advantage of the single-point configuration is that it helps control conductively-coupled interference. As illustrated in figure 3-36, closed paths for noise currents in the signal ground network are avoided by the single point signal reference subsystem. The interference voltage, VN in figure 3-36, in the facility ground system is not conductively coupled into the signal circuits via the signal reference subsystem. Therefore, the single-point signal reference subsystem minimizes the effects of lower frequency noise currents, which may be flowing in the facility ground.

Company advantages

Main brands: ABB, GE/FANC, FOXBORO, Invensys TRICONEX, Bentley BENTLY, A-B Rockwell, Emerson, OVATION, MOTOROLA, XYVOM, Honeywell HONEYWELL, Rexroth, KUKA, NI, DEIF, Yokogawa, Woodward WOODWARD, Ryan, Schneider SCHNEIDER, Yaskawa, Moog, PROSOFT, etc

Application industry: widely used in metallurgy, oil and gas, glass manufacturing, aluminum, petrochemical, coal mine, paper and printing, textile printing, machinery, electronic manufacturing, automobile manufacturing, tobacco, plastic machinery, electricity, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution, etc.
