ADEPT 10332-00505 Channel temperature module

The 2301D-ST has three other discrete input channels that are available for use. These contacts are configurable and can be programmed to perform one of the following functions:  IDLE - RATED SPEED When the state of this contact is open the speed reference moves toward the programmed IDLE speed setpoint at it’s own configured rate set in service menus. When the state of this contact is closed the speed reference moves toward the programmed RATED speed setpoint at it’s own configured rate set in service menus.

52G BREAKER

The state of this input should directly reflect the state of the unit’s generator breaker. This input is used to activate the correct control mode. When this contact input is open, the droop is enabled. When this contact input is closed the unit will be in the isochronous mode. Typically when used as the isoch/droop select contact, this contact is wired to directly reflect the state of the system’s utility tie breaker, with a switch or relay wired in series with the tie breaker aux contact to allow users to manually select the load mode the control operates in when paralleled to the utility. The control is always set to droop mode by opening the 52G BREAKER input.
