  • GE DS200SLCCG1AEG Transfer switch module
GE DS200SLCCG1AEG Transfer switch module

GE DS200SLCCG1AEG Transfer switch module

GE DS200SLCCG1AEG Transfer switch module

Make resistance checks at the actuator. Coil resistance on Woodward actuators is approximately 35 Ω. (Read with leads at terminals 13 and 14 disconnected.)Check Shutdown status in the Service Menu C** SHUTDOWN** #01. If the status is TRUE, check all Shutdown causes; release each cause one by one.

Actuator or linkage.

Check actuator or linkage for proper installation and operation. Problems may be oil supply, direction of rotation, insufficient drainage, linkage, worn actuator components, or improper adjustment. No actuator voltage at terminals 13 and 14. Check for shorted or grounded actuator leads by removing wires to terminals 13 and 14. Stop prime mover. Check for 18 to 24 V at terminals 13 and 14. Check that A**DISPLAY ANALOG INFO** Menu is reading the turbine speed during spinning. If no speed-reading, check the MPU.




Professional seller

Professional sales of major electrical brand products in the world

Overseas direct purchase of products, authentic inventory, price concessions

After sales warranty, complete models, same products, different prices and services


This article from the temporal Ming sheng automation equipment co., LTD., reproduced please attach this link: http://www.stockdcs.com/


Obtain the latest price of GE DS200SLCCG1AEG Transfer switch module
