ABB AX722F 3BDH000377R0001 module

General Information

• Product ID:3BDH000377R0001

• ABB Type Designation:AX 722F

• Catalog Description:AX 722F Analog Input/Output Module

• Long Description:The analog input/output module AX 722F offers even more flexibility, as it combines analog input and output channels in one module with 16 channels.
  Eight of these channels can be individually configured as analog inputs, which can again sense voltage, current, or temperatures. Furthermore four channels can be configured as analog voltage outputs (-10 V to +10 V) or analog current outputs (0 … 20 mA or 4 … 20 mA) and the remaining four channels can provide voltage signals in the range from -10 V to +10 V.
  The inputs and outputs are electrically isolated from the other electronic circuitry of the module. There is no potential separation between the channels.
  This module is usable for PROFIBUS remote I/O and AC 700F / AC 900F direct I/O.

Additional Information

• Medium Description:For PROFIBUS Slave and direct I/O.
  A 16 channel analog input/output module
  8 AI: +-10 V, 0/4-20 mA, RTD, 24 VDC
  4 AO: 0..+ 10V, +-10 V, 0/4-20 mA
  4 AO: +- 10V
  12 Bit + sign, 2-wire, 24 VDC 5 W
  Use with TU 715F / TU 716F

• Technical Information:8 AI: +-10 V, 0/4-20 mA, RTD, 24 VDC
  8 AO: +-10 V, 0/4-20 mA
  12 Bit + sign, 2-wire, 24 VDC 5 W
  Use with TU 715F / TU 716F

Dimensions

• Product Net Depth / Length:54 mm

• Product Net Height:76 mm

• Product Net Width:67.5 mm

• Product Net Weight:0.13 kg
