URRHH Relay module

17-pin circular connector with crimp contacts The following drawing shows the order in which the connector elements are assembled. To meet the requirements of the protection system IP54, both parts of the connector housing must be firmly screwed down using a special tool available at KEBA.

HT Junction Box JB 217 (M-No.: 23830) The junction box is used to integrate the KEBA handheld terminal into the machine/plant. The following connectors are provided for that purpose: S1 17-pin flange socket for connecting the handheld terminal assembled by KEBA. S2 9-pin SUB-D female connector for connecting a program loading cable (RS-232-C interface). S3 9-pin SUB-D female connector for connecting a PLC connecting cable. K1 12-pin terminal block for connecting power supply, emergency stop switch and enabling switches.The handheld terminal meets the safety class III in accordance with EN61131-2 and EN50178. When connecting the handheld terminal, make sure that all voltages connected to the handheld terminal are safety low voltages and isolated from the low voltage supply system by a safety transformer or a similar facility.

Programming the HT

 For setting the configuration of the device and for generating texts and the keyboard layout, a programming software executable under MS-Windows (3.11, 95, NT,...) is supplied. This software provides functions for creating configuration data, for editing text lines and the keyboard layout and for loading the program. The operation of the software is menu-driven. 6.1 Hardware Required For programming the device configuration, the following hardware components are required: ❏ HT 40x ❏ Programming PC with HT4xx programming software (HTWIN) ❏ 24V DC power unit for HT 40x power supply ❏ Connection cable between serial interface (RS-232-C) HT-COM1 or HT-COM2 on HT 40x and one free serial interface on the programming PC (COM1, COM2,...) The electrical connections required are described in the chapter „Basic Wiring Diagram“. For connecting the HT 40x, a junction box (see chapter „Serial connection with 2-channel enabling switch“) can be used alternatively.
