The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

Products are widely used in metallurgy, petroleum, glass, aluminum manufacturing, petrochemical industry, coal mine, papermaking, printing, textile printing and dyeing, machinery, electronics, automobile manufacturing, tobacco, plastics machinery, electric power, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution and so on.

LDGRB-01 3BSE013177R1 GRBTU module

Grounding the controller and screening the electronic components requires a grounding cable of at least 6mm² to be laid between the grounding stud of the controller to the central grounding point of the machine. The other devices of the machine must be grounded in a starshaped configuration (see Fig. 1-8: System grounding with PPC-R). The power supply must be grounded in the same way.

A maximum of 4 module carriers RMB02.2-04 can be installed side by side. To be able to address the module carriers, there is a DIP switch on the bus board of the module carriers. Depending on the module carrier, the switch must be set to the corresponding module carrier number (module carrier address 00-03, see diagram below). Each module carrier number may only be set once.

Rexroth Indramat products represent state-of-the-art developments and manufacturing. They are tested prior to delivery to ensure operating safety and reliability. The products may only be used in the manner that is defined as appropriate. If they are used in an inappropriate manner, then situations

Important directions for use

Rexroth Indramat, as manufacturer, is not liable for any damages resulting from inappropriate use. In such cases, the guarantee and the right to payment of damages resulting from inappropriate use are forfeited. The user alone carries all responsibility of the risks. Before using Rexroth Indramat products, make sure that all the prerequisites for appropriate use of the products are satisfied: • Personnel that in any way, shape or form uses our products must first read and understand the relevant safety instructions and be familiar with appropriate use. • If the product takes the form of hardware, then they must remain in their original state, in other words, no structural changes are permitted. It is not permitted to decompile software products or alter source codes. • Do not mount damaged or faulty products or use them in operation. • Make sure that the products have been installed in the manner described in the relevant documentation.

Areas of use and application

The PPC-R01.2 and PPC-R02.2 units made by Rexroth Indramat are designed for installation in the RECO02 module carrier system. The PPC-R unit is designed for use in the following cases: • as control for Motion- and PLC applications Note: The PPC-R unit may only be used with the accessories and parts specified in this document. If a component has not been specifically named, then it may not be either mounted or connected. The same applies to cables and lines. Operation is only permitted in the specified configurations and combinations of components using the software and firmware as specified in the relevant function descriptions. Available for an application-specific use of the PPC-R unit are configurations with different field buses and different serial interfaces. Typical areas of application of a PPC-R unit are: • Printing and Paper • Packaging • Machine tools • Machining center The PPC-R unit may only be operated under the assembly, installation and ambient conditions as described here (temperature, system of protection, humidity, EMC requirements, etc.) and in the position specified.
