ABB DSQC500 3HAC3616-1 Computer board connector

ABB DSQC500 3HAC3616-1 Computer board connector

Connect the P2 Adapter Board or LCP2 Adapter Board and cable(s) to MVME162 backplane connector P2. This provides a connection point for terminals or other peripherals at the EIA-232-D serial ports, SCSI ports, and LAN Ethernet port. For information on installing the P2 or LCP2 Adapter Board and the MVME712 series transition module(s), refer to the manuals listed in Related Documentation in Chapter 1 (the MVME162 Embedded Controller Programmer’s Reference Guide provides some connection diagrams.) 9. Connect the appropriate cable(s) to the panel connectors for the EIA-232- D serial ports, SCSI port, and LAN Ethernet port. – Note that some cables are not provided with the MVME712 series module and must be made or purchased by the user. (Motorola recommends shielded cable for all peripheral connections to minimize radiation.)
