ABB RDIO-01 Digital IO expansion

ABB RDIO-01 Digital IO expansion

On Revision A and B modules, jumper W11 carries the SLOT0SEL* signal from the rear signal connector, after buffering, to the SCXIbus INTR* line. Leave jumper W11 in the factory-set position (position A-B). On Revision C or later modules, jumper W11 does not exist. - On Revision A and B modules, jumper W13 is unused and you should not connect it. • User-configurable jumpers - Jumpers W1 through W8 ground the negative inputs of each input through 100 kΩ resistors for floating sources and transducers. - Jumper W9 allows the module to connect to a single-ended data acquisition board instead of a full differential board. - Jumper W12 determines the connections between the SCXIbus guard, chassis ground, and the data acquisition board analog ground.
