See the Timing Requirements and Communication Protocol section later in this chapter, and Chapter 5, Programming, for information on using the INTR* line. See Appendix E, SCXI-1140 Cabling, for pin equivalences of the SCXI-1140 rear signal connector and the data acquisition board I/O connector.Position B-C is reserved and you should not use it. On Revision C or later modules, jumper W11 does not exist. SLOT0SEL* is always buffered to the INTR* line. Jumper W14 Position A-B connects the SCXIbus MISO line, after buffering, to the SERDATOUT pin of the rear signal connector. When jumper W14 is in Position A-B and jumper W13 is properly set, the data acquisition board can read the Module ID Register of the SCXI-1140. See the Timing Requirements and Communication Protocol section later in this chapter, and Chapter 5, Programming, for information on reading the Module ID Register. See Appendix E, SCXI-1140 Cabling, for the SCXI-1140 rear signal connector and the data acquisition board I/O connector pin equivalences.
