ABB IMSET01 Event timing module

ABB IMSET01 Event timing module

Pin Signal Name Description B2 AB0+ Analog Bus 0+ – Positive analog bus 0 line. Used to multiplex several modules to one analog signal. C2 AB0- Analog Bus 0- – Negative analog bus 0 line. Used to multiplex several modules to one analog signal. A1, B1, C1, D1, GUARD Guard – Shields, guards the analog bus lines from noise. A2, B2, C2, D2, A3, B3, C3, D3, A5, B5, C5, D5, A4, D4, A6, D6 C13-C17, CHSGND Chassis Ground – Digital and analog ground reference. A21, B21, C21, D21 A13 TRIG4 TRIG4 – Reserved. Open collector. C18 RSVD Reserved.
