LENZE EPL-10200-XX Drive the timer

Swivel angle transducer DK100 can be connected using a 5-pin mating connector 130-9 IEC-22 to DIN 45 321, which can be ordered separately. Up to a length of 50 m we recommend the use of 4 x 0.25 mm² cables of type LiYCYCY as connection cable. When double shielded cable is used, the outer shield can be terminated at the entry into the control cabinet, the inner shield can be terminated at the control electronics. Depending on the mechanical mounting of the swivel angle transducer, positive feedback may occur. In this case, exchange connections f20 and f26. A2V...EO4 housing pump: Type MCP-40/4742 The Figure below shows the connection of the swivel angle transducer.The transducer is connected by means of soldered connections. Up to a length of 50 m we recommend the use of 3 x 0.5 mm² cables of type LiYCYCY as connection cable. When double-shielded cables are used, the outer shield can be terminated at the entrance in the control cabinet, the outer shield can be terminated at the control electronics.

Initial commissioning

 The proceeding for commissioning the control electronics VT-VPCD depends on various factors on site. For this reason, only basic steps for commissioning can be described in these instructions. 8.1.1 Establishing operational readiness To establish operational readiness of the control electronics: 1. Thoroughly inspect the cabling 2. Apply voltage to the control electronics VT-VPCD The control electronics runs a short internal function test. The display of the control electronics shows the manufacturer’s name in red scrolling text (during initial commissioning). See Chapter 5.2.3 “Display and operating elements and test sockets“ on page 23. For the voltage interface, pressure transducers of type HM 20 -2X/...H-K35 are used. Pressure transducer cables must be shielded. Cable type for the voltage interface: LiCYC 4 x 0.25 mm2 up to a length of 50 m.For the current interface, pressure transducers of type HM 20-2X/...C-K35 are used. Pressure transducer cables must be shielded. Cable type for the current interface: LiCYC 2 x 0.25 mm2 up to a length of 50 m.

System requirements

IBM-compatible PC with the following minimum requirements: • Operating system: Windows XP, Windows Vista, Windows 7. • 256 MB RAM recommended • Hard disk with at least 250 MB free hard disk space • CD-ROM drive or Internet access • RS232 interface (or USB port in conjunction with an USB converter, Mat. no. R901066684) Start the setup routine for installing software BODAC by executing the file “Setup. exe”. To install the software BODAC: 1. Insert the CD-ROM and locate the file “Setup.exe” or download the file on the Internet. 2. Double-click on file “Setup.exe“ . The setup program will load and display a start screen. 3. Follow the instructions on screen to run the setup routine. BODAC is installed.
