ABB IOS-01 E-31701 Robot I/O board

ABB IOS-01 E-31701 Robot I/O board

Configure jumper W1. 3. Install the SCXI module in the chassis. 4. Connect one end of the ribbon cable to the adapter board rear connector. This is the 50-pin connector of the SCXI-1344 cable. 5. Plug the adapter board front connector to the module rear signal connector. A corner of the adapter board will enter the upper board guide of the chassis. 6. Screw the rear panel to the threaded strips in the rear of the chassis. 7. For an SCXI-1341, connect the loose end of the ribbon cable to the Lab board I/O connector. For an SCXI-1344, connect the two 26-pin connectors to the Lab-LC according to the instructions given in the Installation section of Chapter 2, Configuration and Installation, of the Lab-LC User Manual.
