HONEYWELL 05701-A-0330 The spare parts

will be displayed for approx. 2 s if the checksum is not correct. The device changes to the "Configuration Loader" mode. A new start is only possible after turning off and on the device. Checking the keyboard matrix for pressed keys.will be displayed if one or more pressed keys have been found during testing. The device remains in this condition as long as the keys remain pressed. After the keys are released, the handheld terminal continues performing the self-test. After the flash memory test, the system program is invoked. What will be displayed further depends on the program.To enter the main menu, press the keys 1 and 4 simultaneously after turning on the handheld terminal. The headline "MAIN MENU" appears. After you release the keys, the menu itself is displayed. 1 2 3 4 MAIN MENU Press these keys Key 1 and key 4 after turni For the following menus, the keys of the first row on the handheld are available as softkeys. The last display line indicates the functions assigned to the keys of the first row. Notice The access to the main menu can also be deactivated. For details about the deactivation, refer to the specific coupling manual. In all menus the key 1 always has the function of an ESC key. Apart from few exceptions, the keys 2,3 are used to move the brackets "> <", that identify the menu line to be selected, up and down. The key 4 (OK) confirms the selection.

Diagnosis Menu

 The diagnosis menu is a submenu of the main menu and provides different test functions:Keyboard Test Tests the HT keyboard. Apart from key 1 that acts as ESC key, all keys pressed are displayed one after the other in the line "Pressed Key:". Buzzer Test The buzzer remains turned on until you quit the menu by pressing ESC. I/O STATUS The following display is continuously updated: I/O Status AI1:xx Handwh.:xxxxx AI2:xx DI:uvw Stop:x Esc AIx A/D input (override potentiometer). The value range 0 to 63 is displayed according to the position of the override potentiometer. At devices without override potentiometer, the value displayed is 0. Handwh Count of handwheel. Each lock-in position increments or decrements the count. 100 lock-in positions =1 revolution. The counter values range from 0 to 65535. DI Digital inputs. Indicate the current status of the 3 digital inputs: u .................................. DI 1 v................................... DI 2 w.................................. DI 3 At present, only DI 1 is used. It indicates the status of the key switch: DI 1 = 1........................ not actuated DI 1 = 0........................ actuated DI 2 and DI 3 are reserve inputs. Stop Status of emergency stop switch of HT (1=activated) Esc Back All interfaces available in the handheld terminal can be selected for testing. They can be tested without being connected to the PLC:At the interface to be tested, the transmitter and the receiver must be linked together (e.g. directly on connection board or on-site at the end of the signal lines).
