B&R 5AP920.1505-01 Touch screen

Almost one common + has to be connected to the power supply. When switching high current loads, use many commun + terminal to avoid damage to the base. Warning : For a version dated before 01/92, the terminals 4 and 5 have not be used. Internal connection Note : In case of use of an external power supply 24 V DC for inputs, the "24" V DC has to be connected to the common "+". Caution : if the 24 V DC is connected to common "+", the remote unit can be supplied by the external power supply even if the main power supply is OFF. ● Initialization After configured and wired the unit : – the unit initializes itself after power On. – the error led goes out after initialization. – the status of 8 inputs is displayed on the 8 led's.

The available configuration for each input : – delay – open circuit detection A channel can be used for an input or an output, depending upon the user program. Note : The inputs/outputs are configurated in outputs when the DIP switch N° 1 on the plug-in base ECZ is ON. This allows to use again the address coded for an input unit.

Intended purpose

 The binary input/output module ICDG 32 L1 is a remote module on the CS31 system bus. It has 32 binary channels with the following features:
16 inputs, 24 V DC, in 2 groups
8 outputs, 24 V DC, in 1 group. The outputs employ switching transistors, have a rated load capability of 0.25 A and are overload and short-circuit proof.
8 inputs/outputs, of which each can be addressed as an input, as an output as a readable output (combined input/output). In this case the technical data are equal to the data of the other inputs and outputs. The module is supplied with 24 V DC. The CS31 system bus connection is electrically isolated from the remaining module components. The module offers a number of diagnosis functions (see chapter ”Diagnosis and displays”). Display and operating elements on the front panel 16 green LEDs for displaying the signal statuses of the inputs, 16 yellow LEDs for displaying the signal statuses of the outputs or of the combined inputs/outputs List of diagnosis information belonging to the LEDs, if they are used for diagnosis Red LED for error message  Test button

Electrical connection

The module is mounted on a 15-mm-high DIN rail or fastened with 4 screws. The following figure shows the electrical connection of the input/output module.

Addressing An address has to be set on each module, so that the central unit can access the inputs and outputs correctly. A detailed description concerning the item ”Addressing” is contained in the chapters ”Addressing” of the central units and couplers. The module address is set on the DIL switch located under the slide on the right side of the module. If the central units 07 KR 91, 07 KT 92 and 07 KT 93 are used as bus masters, the following operating modes (address allocations) are valid
