MVME2434 Channel isolation card

Overvoltage category II according to IEC 65 A Buffered voltage interruption time for the processor part > 10 ms for the outputs none Protection against reversed connection of supply voltage yes Conductor cross section for the removable terminal blocks supply voltagemax. 2.5 mm2 CS31 system bus max. 2.5 mm2 input/output terminals max. 1.5 mm2 Number of binary inputs 16 Number of binary transistor outputs 8 Number of combined inputs/outputs 8 Reference potential for all inputs and outputs terminals 24/25 (minus pole of the supply voltage, signal name M) Number of interfaces 1 CS31 system bus interface Electrical isolation CS31 system bus interface versus the remaining module parts Address setting with a DIL switch located under the slide on the right side of the module Diagnosis see chapter ”Diagnosis and display” Indication of operating statuses and errors 33 LEDs altogether Mechanical dimensions 120 x 140 x 85 mm Weight 450 g

● Fault indication

The internal 24 VDC (100 mA) power supply is only available for the 230 VAC/120 VAC versions. This power is used to power the inputs. In case of the 24 VDC version, the 0 V of the second external power supply for the inputs has to be connected to the common "–". The 0 V of the 24 VDC power supply for the outputs has to be connected to the common M-T -. If the 24 VDC of the external supply is not connected to the common M-P +, the outputs are reset to 0. – A free wheel diode is not necessary because the protection is integrated into the transistor component. – An external thermal fuse max. 5 A has to be connected between the common + terminals and the 24 VDC to avoid damage in case of use of a lot of overload outputs. ● Initialization After configured and wired the unit : – the unit initializes itself after power On. – the error led goes out after initialization. – the status of inputs/outputs is displayed on the 20 led's.

Intended purpose

The binary output module ICPO 16 H1 is a remote module on the CS31 system bus. It has 16 binary channels with the following features:
Housing and termination system according to IP65 degree of protection
The CS31 bus line is looped through from module to module. For this purpose, the module has two bus connectors as bus input and bus output.
Each output has its own connector and thus can be unplugged individually.
The 24 V DC supply voltage is connected via screw–type terminals inside the module housing.
The outputs employ switching transistors, have a rated load capability of 2 A and are overload and short–circuit proof. The module is mounted with screws. There are bore holes available for both mounting on a rear wall or on a horizontal surface.
