YOKOGAWA AIP578 Input module

This card is a 32 channel binary inputs/ outputs card for communication between the CS31 system and ABB type S3 robots (it is mounted in the robot rack). The power supply is taken from the robot rack. The CS31 system bus is used for the communication. The card is seen as a standard input/output unit by the robot and CS31 system.

Connection The address of the card is set with the dil switch SW1 in the same manner as the plug-in base. Connect the CS31 bus to the connector X1 of the card with the special cable (YB560105-DZ ABB Robotics) Connect the wires of this cable to the CS31 bus.Insert the card into a binary input/output slot of the robot rack (refer to robot documentation for user details).

Initialization

 The card initializes itself after powered on the robot and the CS31. The input led's 1,2,8 et "F" are illuminated. – After a correct initialization, the error led "F" switch off, The input led's take their function, the system is now ready to run.

This card is used like a standard remote binary input/ output unit. The usual instructions are used to read inputs and write outputs. This card is used like one DSQC 223 by the robot. Each output bit of the robot is an input bit of the CS31. Each input bit of the robot is an output of the CS31. Example : The robot sets output 5 to 1. This is read using the input (Exx,05 or Ixx 05). In the same way input 7 of the robot can be set by writing to Axx,07 or Oxx,07 of the CS31. The function of the led's on the front of the card can be selected by pressing the "SELECT" push-button on the card (I/O status or address and diagnosis). – The "I/O" led is illuminated when the led's indicate the input/ouput status. – The "ADR" led is illuminated when the led's indicate the setting of SW1.

Robot card

This card is a 64 channel binary inputs/ outputs card for communication between the CS31 system and ABB type S3 robots (it takes two slots in the robot rack). The power supply is taken from the robot rack. The CS31 system bus is used for the communication. The card is seen as a standard input/output module by the robot and CS31 system.
