RELIANCE 0-52859-2 Switching module

 This section provides the information necessary to install the XVME-660 into the VMEbus backplane. The XVME-660 is a double-high, two-slot VMEbus module Do not use excessive force or pressure to engage the connectors. If the boards do not properly connect with the backplane, remove the module and inspect all connectors and guide slots for damage or obstructions.

Installing the XVME-660 into a Backplane

1. Disconnect all power supplies to the backplane and the card cage. Disconnect the power cable. 2. Make sure backplane connectors P1 and P2 are available. 3. Verify that all jumper settings are correct. 4. Verify that the card cage slot is clear and accessible. 5. Install the XVME-660 in the card cage by centering the unit on the plastic guides in the slots (P1 connector facing up). Push the board slowly toward the rear of the chassis until the P1 and P2 connectors engage. The board should slide freely in the plastic guides.
