The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

Products are widely used in metallurgy, petroleum, glass, aluminum manufacturing, petrochemical industry, coal mine, papermaking, printing, textile printing and dyeing, machinery, electronics, automobile manufacturing, tobacco, plastics machinery, electric power, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution and so on.

5SHY3545L0016 3BHB020720T0002 Thyristor module

Creation of the user program using the programming languages – Extended instruction list (ext. IL) – Function block diagram (FBD) and – Ladder diagram (LD) Test in ext. IL, FBD and LD (see 907 PC 331)
Test in terminal mode, e.g. in the programming software 907 PC 331 (main menu ”PLC commun. 2”, submenu ”Terminal emulation”)
Test Press the followingin order to activate the terminal mode:, <1> for TERMINAL, <2> for CHAR. MODE andfor data rate unchanged. For the interfacing to the 07 KR 91 / 07 KT 92/93 see the following. In order to establish the connection between the programming and test tools and the central unit 07 KR 91 / 07 KT 92 / 07 KT 93, the serial interface COM1 of the central unit 07 KR 91 / 07 KT 92 / 07 KT 93 has to be set to ”Active mode” in all cases, see chapter ”Serial interface COM1” in the description of the central unit.

Setting the operating modes The constants KW 00,00...KW 00,15 are reserved as system constants. Even the constants KW 00,13...KW 00,15 which are not used yet may under no circumstances be used for other purposes.

First-cycle detection

M 255,15 This binary flag can be used for detection of the first program cycle after a program start. It is always set to ”zero” after each program start, independent of the initialization instructions given by the system constants. If this flag is read by the user program and then set to ”1”, it can be found out whether or not the user program was started once more.

CS31 status word EW 07,15 Bit 0 = 1 : No class 2 error present. Bit 1 = 1 : PLC has been adopted into the CS31 bus cycle (only relevant if used as a slave). Bit 2 = 1 : Time and date are valid. Bit 3 = 1 : Battery is effective. Bit 4...7 : Not used. Bit 8..15 : Maximum number of modules on the CS31 system bus, found out until now (only relevant if used as a master).

System constants / Setting of operating modes

Definitions Cold start – All of the RAM memories are tested and deleted. – If there is no user program in the Flash–EPROM, the default values are set to all of the system constants (identical to the factory settings). – If there is a user program in the Flash–EPROM, this program is loaded into the RAM including the system constants. – The operating modes given by the system constants are set. – The CS31 system bus is initialized again(only when used as a master on the CS31 system bus). Performing a cold start – Power OFF/ON, if there is no backup battery or – Command KALTin terminal mode (see volume 7.3) or – Menu field ”Cold start” in the programming system

Warm start – All of the RAM memories, with the exception of the program memory and the operand memory (flags), are tested and deleted. – If there is a user program in the Flash–EPROM, this program is loaded into the RAM including the system constants. – The operating modes given by the system constants are set. – The CS31 system bus is initialized again(only when used as a master on the CS31 system bus).
