The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

Products are widely used in metallurgy, petroleum, glass, aluminum manufacturing, petrochemical industry, coal mine, papermaking, printing, textile printing and dyeing, machinery, electronics, automobile manufacturing, tobacco, plastics machinery, electric power, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution and so on.

SM811K01 32SE018173R1 processor module

Output of 3 values after entering a semicolon (;) Command ZZA permits you to display the values (byte or word) of maximum 3 addresses each time a semicolon (;) is entered. The command can be aborted with. B: Byte-serially (keyword) W: Word-serially (keyword) adr1: 1st address whose value is displayed on the monitor. adr2: 2nd address whose value is displayed on the monitor. adr3: 3rd address whose value is displayed on the monitor. ,: Keyword (separator) Example: ZZA 1000:0, 1000:100After entry of a semicolon (;), the values of addresses 1000:0H and 1000:100H are displayed on the monitor. Search for string Command ZZF can be used to search for a string with maximum 3 words in the specified memory area. If the string is found, the address is displayed on the monitor. The search is continued by entering a semicolon (;). If the string is not found, monitor message <#07> is displayed.Start address of the memory area ea: End address of the memory area L: Length (keyword) az: Number of words in the memory area exp1: 1st word of the string exp2: 2nd word of the string exp3: 3rd word of the string ,: Keyword (separator)

Compare memory areas word–serially

Command ZZV is used to compare a memory area 1 word-serially with a memory area 2. If a difference is established, the address 1, the contents 1, the address 2 and the contents 2 are displayed on the monitor. The operation can be aborted with CTRL C.

aa1: Start address of the memory area 1 ea1: End address of the memory area 1 L: Length (keyword) az1: Number of words in the memory area 1 aa2: Start address of the memory area 2 ,: Keyword (separator) Example: ZZV A000:0 L 100, 8000:0Memory area 1 between A000:0H and A000:100H is compared with memory area 2 as of 8000:0H.The W command permits a data area of the PLC to be output as an INTEL HEX file via the serial interface COM2 of the unit 07 KT 92. The following records are generated in this case: address extension record data record end record The following transfer format applies: 8 data bits no parity bit 1 stop bit

Read Intel HEX file

 Using the R command, it is possible to read in an INTEL HEX file via the COM2 serial interface of unit 07 KT 92 and to store the HEX file data in the PLC. The following records are accepted in this case: address extension record data record end record The following transfer format applies: 8 data bits no parity bit 1 stop bit The data of the INTEL HEX file are stored in the PLC as of the following address:
The segment address is determined by the address in the address extension record of the INTEL HEX file. If an offset is specified when entering the command, this offset is added to the segment address in the address extension record. This results in a new segment address as of which the data of the HEX file are stored. This permits the storage area for the HEX file data in the PLC to be preset.
The offset address is determined by the address in the data record of the INTEL HEX file.
