1746-NO4V/A Communication module

The device is 85 mm deep. The interface connectors RCOM and CONSOLE are set deeper so that the mounting depth required does not become any larger even with detachable interface cables. If, however, a DIN rail is used, the mounting depth is increased by the overall depth of the rail

Mounting hints Mounting position vertical, terminals above and below Cooling The natural convection cooling must not be hindered by cable ducts or other material mounted in the switch cabinet.

Apart from the basic ”Regulations for the Setting up of Power Installations” DIN VDE* 0100 and for ”The Rating of Creepage Distances and Clearances” DIN VDE 0110 Part 1 and Part 2 the regulations ”The Equipment of Power Installations with Electrical Components” DIN VDE 0160 in conjunction with DIN VDE 0660 Part 500 have to be taken into due consideration. Further attention has to be paid to DIN VDE 0113 Part 1 and Part 200 in case of the control of working and processing machines. If operating elements are to be mounted near parts with dangerous contact voltage DIN VDE 0106 Part 100 is additionally relevant.

If the protection against direct

 contact according to DIN VDE 0160 is required, this has to be ensured by the user (e.g. by incorporating the elements in a switch-gear cabinet). The devices are designed for pollution severity 2 in accordance with DIN VDE 0110 Part 1. If higher pollution is expected, the devices must be installed in appropriate housings. The user has to guarantee that the devices and the components belonging to them are mounted following these regulations. For operating the machines and installations, other national and international relevant regulations, concerning prevention of accidents and using technical working means, also have to be met. The ABB Procontic devices are designed according to IEC 1131 Part 2. Meeting this regulation, they are classified in overvoltage category II which is in conformance with DIN VDE 0110 Part 2. For the direct connection of ABB Procontic devices, which are powered with or coupled to AC line voltages of overvoltage category III, appropriate protection measures corresponding to overvoltage category II according to IEC–Report 664/1980 and DIN VDE 0110 Part 1 are to install.

Brief description

 The 07 KP 92 R101 communication module is a freely programmable interface module with 2 serial interfaces. The communication module allows external units to be connected to the ABB Procontic CS31 system via a serial interface. The communications protocols and transmission types can be freely defined by the user. Programming is performed on a PC with the programming and test software 907 KP 92. The communication module is connected to ABB Procontic CS31 central units via the networking interface, e.g. 07 KR 91 (index h onwards), 07 KR 91 R252, 07 KT 92 (index i onwards) or 07 KT 93. The most important features of the communication module are:
2 serial interfaces, optionally configurable in accordance with EIA RS–232 or EIA RS–422 or EIA RS–485 (COM3, COM4)
Freely programmable with a comprehensive function library
Communication with ABB Procontic CS31 central unit via connection elements
Configurable LEDs for diagnosis
Programming and testing on a PC via COM3 or COM4
Saving applications in a Flash EPROM Processing of the serial interfaces and the networking interface is provided for in an applications program. Programming is in a language similar to the standard language ”C”. It provides elements for structuring and a comprehensive library for using the interfaces. The exchange of data between the serial communication module and the ABB Procontic CS31 central unit is realized by connection elements in the central unit.
