HONEYWELL CC-PAIM01 Actuator module

When operating with the UCZA, the cannels 8 to 15 cannot be used with the CS31 designator with the valve/installation island. They are available for other CS31 modules.
The setting for channel <7 or >7 is omitted for the valve / installation island.
Error displays on the device: – Green LED lights up: Operating voltage is present – Red LED lights up: Hardware error or short– circuit or voltage is too low. – Red LED flashes quickly: Baud rate or address is incorrect. – Red LED flashes slowly: Bus connection is not okay.
Error displays are automatically deleted after remedying the error.
Note: For T200 coupling: Configuration type EA16

For the coupler 35 CS 91 (ABB Procontic T300), the assignment is freely programmable, see the description of the coupler 35 CS 91 (in preparation) in the system description ABB Procontic T300, order No. GATS131599R2002.
When operating with the UCZA, the cannels 8 to 15 cannot be used with the CS31 designator with the valve/installation island. They are available for other CS31 modules.
The setting for channel <7 or >7 is omitted for the valve / installation island.
Error displays on the device: – Green LED lights up: Operating voltage is present – Red LED lights up: Hardware error or short– circuit or voltage is too low. – Red LED flashes quickly: Baud rate or address is incorrect. – Red LED flashes slowly: Bus connection is not okay.
Error displays are automatically deleted after remedying the error.
Note: For T200 coupling: Configuration type EA16

Intended Purpose

 The cable 07 SK 90 is used to connect a 9–pole serial interface connector of CS31 compact PLCs or T200 communication processors with a peripheral unit in order to operate in programming or active mode (see 13.8.1 Survey table). If the peripheral unit has a 9–pole connector, the adaptor provided with (25–pole to 9–pole) can be employed for adaption. Mechanical Design Plug 1 SUB–D plug, 9–pole male, on the side of 07 KP 6x, 07 KR 91, 07 KT 92. The housing is metal–plated, the shield is connected to the metal plate. Plug 2 SUB–D plug, 25–pole female, on the side of the peripheral unit. The plugs are mounted to both interfaces by means of screws. Cable type LICYCY 5 x 0.14/15 Adaptor provided 25–pole male/9–pole female for connection of peripheral units with 9–pole interfaces (male) Technical Data Length 5 m Weight 220 g Order number GJR5 2502 00 R1

Interface Cable 07 SK 91 R1 with adaptor

The cable 07 SK 91 is used to connect a 9–pole serial interface connector of CS31 compact PLCs or T200 communication processors with a peripheral unit in order to operate in MMC mode or passive mode (see 13.8.1 Survey table). If the peripheral unit has a 9–pole connector, a commercially available adaptor (25–pole to 9–pole) has to be employed for adaption. Mechanical Design Plug 1 SUB–D plug, 9–pole male, on the side of 07 KP 6x, 07 KR 91, 07 KT 92. The housing is metal–plated, the shield is connected to the metal plate. Plug 2 SUB–D plug, 25–pole female, on the side of the peripheral unit. The plugs are mounted to both interfaces by means of screws. Cable type LICYCY 5 x 0.14/15 Adaptor provided 25–pole male/25–pole male for connection of peripheral units with 25–pole interfaces (female) Technical Data Length 5 m Weight 220 g Order number GJR5 2503 00 R1
