The GE VMIVME-2128 is a high-voltage digital output board designed for use in industrial automation and control applications. The board is designed to provide high-speed, high-voltage output signals to control devices such as motors, valves, and other actuators.

The VMIVME-2128 board is designed to fit into a VME bus rack, which is a standard platform used in industrial control and automation systems. The board has 16 output channels, each of which is capable of providing a high-voltage output signal up to 100V or 150V depending on the model.

The board uses a combination of solid-state relays and high-power output drivers to provide fast and reliable switching of high-voltage loads. The solid-state relays are used to switch low-current signals, while the output drivers are used to switch high-current signals.

The VMIVME-2128 board is typically controlled by a host computer or programmable logic controller (PLC) using standard digital input/output (I/O) signals. The board also features on-board status LEDs to indicate the status of each output channel.

• 128 bits of high-voltage outputs

• High-current drivers (600 mA sink)

• Automatic surge current shutdown protection

• Thermal shutdown protection

• High breakdown voltage (55 V)

• Output clamp diodes for inductive flyback protection

• Compatible with Intelligent I/O Controllers

• Built-in-Test logic for fault isolation

• VMEbus compatible (ANSI/IEEE STD 1014-1987 IEC 821 and 297)

• A24:A16:D32/D16/D08 (EO): slave 39/3D:29/2D:6U form factor

• Optional pull-up resistors for electronic switch outputs

• Front panel with fail LED

• Sockets are provided for warming resistors, which are supplied by the user
