ABB PPD113B01-10-150000 3BHE023784R1023 controller

ABB PPD113B01-10-150000 3BHE023784R1023 controller

ABB PPD113B01-10-150000 3BHE023784R1023Color code Dark red Number of input points 32, commoned in groups of 8 Recommended input range 20–42.5 VDC Maximum voltage 42.5 VDC Switching level: Off to On 10 VDC typical, 12 VDC worst-case Switching level: On to Off 5 VDC typical, 4 VDC worst-case Typical hysteresis 2 VDC Nominal turn-on 3 mA to 5 mA Input impedance > 1.25 kΩ nominal Input delay: Off to On < 8 ms Input delay: On to Off < 15 ms Point isolation, opto-isolated 1,000 VAC minimum, 1,500 VDC minimum Status indicator: On or Off State 1 per point Status indicator: Module status Pass, Fault, Active Logic power < 10 watts Nominal field power load 0.5 watts per On pointa 1.5 watts @ maximum field voltage Leakage current to chassis @ 60 Hz 0.25 mA maximum per On point Input diagnostic fault coverage: Maximum input toggle rateb Minimum input toggle rate, On state Minimum input toggle rate, Off state Every 100 ms Not required Every 24 months (manually toggled by the user)ABB PPD113B01-10-150000 3BHE023784R1023

Diagnostic glitch durationd Output voltage Output impedance 20 ms typical < 1/2 VIN < 1.87 kΩ a. When used with ABB PPD113B01-10-150000 3BHE023784R1023a typical shunt-diode intrinsic safety barrier, the nominal field power per On point is approximately 350 milliwatts @ 24 VDC. b. The maximum input toggle rate enables proper operation of I/O diagnostics and detection of all normally detectable faults. c. For more information, see Toggling Field I/O Points on page 288. d. VIN is the voltage applied to an energized point. Output voltage is noticeable on an adjacent deenergized point for the duration of the diagnostic glitch. Be advised that the glitch output may falsely energize the paralleled input of another piece of equipment.ABB PPD113B01-10-150000 3BHE023784R1023

Related products：

ABB 1MYN743217-A Matrix switch card

ABB 1MYN743216-A Multifunctional I/O card

ABB 1MYN743215-B Communication interface card
