The main products

Spare parts spare parts, the DCS control system of PLC system and the robot system spare parts,

Brand advantage: Allen Bradley, BentlyNevada, ABB, Emerson Ovation, Honeywell DCS, Rockwell ICS Triplex, FOXBORO, Schneider PLC, GE Fanuc, Motorola, HIMA, TRICONEX, Prosoft etc. Various kinds of imported industrial parts

DS200TCQCG1BKG Industrial control module

Figure 4-9 Resistor cable stripping diagram (braking chopper end). All lengths are approximate and may vary according to the cable lugs used. • Cut and strip the cable as shown in Figure 4-9 above. • Cut an opening in the grommet at the cable entry. For best results, cut along the appropriate diameter marking. • Lead the cable through the bushing into the converter unit. • Place the strain relief onto the cable insulation and tighten to 6 Nm. • Twist the screen wires together and connect to the earthing clamp on the ACS 600 PE bus, along with conductor no. 3 (if present). Tighten the clamp to 6 Nm. • Crimp cable lugs onto conductors 1 and 2. (The screws on the R+ and R– busbards of the chopper are M8.) • Connect conductor no. 1 to the R+ terminal of the chopper. Support the back nut with a tool and tighten to 16 Nm. • Connect conductor no. 2 to the R– terminal of the chopper. Support the back nut with a tool and tighten to 16 Nm. • Leave enough free space to make subsequent servicing (eg. replacement of the converter cooling fan) easier. (See picture on left.

ACS 600 Connection

Ensure that the UDC+ and UDC– busses of the chopper are properly connected to the corresponding terminals of the ACS 600 (see Chapter 3 – Voltage Selection and Mechanical Installation). Resistor Cable Connection Connections at the braking resistor: (For terminal tightening torques, consult resistor documentation.) • Twist the screen wires together and connect them to the earthing terminal, along with conductor no. 3 (if present). • Crimp cable terminals of appropriate type onto conductors 1 and 2. • Connect conductor no. 1 to the R+ terminal. • Connect conductor no. 2 to the R– terminal.

WARNING! Before installation, switch off the mains supply to the ACS 600. Wait five minutes to ensure that the intermediate circuit is discharged. Switch off all dangerous voltages connected to the inputs or the outputs of the ACS 600.
