TAMAGAWA TS2640N321E64 Channel isolation card

Product parameters

Product ID:MV65WKS-CE310/22PB

Product brand：TAMAGAWA

Product Net Depth / Length:64 mm

Product Net Height:284 mm

Product Net Weight:3.04 kg

Product Net Width:412 mm

Voltage:220V

Made To Order:No

Details description

 The EIA standard for TS2640N321E64 description of the polarity of the signalling lines states: “The signalling sense of the voltages appearing across the interconnection cable are defined as follows: a. The A terminal of the generator shall be negative with respect to the B terminal for a binary 1 (MARK or OFF) state. b. The A terminal of the generator shall be positive with respect to the B terminal for a binary 0 (SPACE or ON) state”. Not all manufacturers use the same convention for the polarity of differential data lines. The System TS2640N321E64 Interface Module is labelled 1A, 1B and 2A, 2B for the primary and secondary transceivers in RS485 mode and A and B for the transmitter and A’ or B’ for the receiver in RS422 mode.

 Where access to the host interface hardware is limited it has been found that a single 120 ohm bias resistor connected between the System 57 terminals TB2 pin 2 and TB2 pin 5 has been effective.
