Home > Product > Servo control system > REXROTH CSB01.1C-PL-ENS-NNN-NN-S-NN-FW module

  • REXROTH CSB01.1C-PL-ENS-NNN-NN-S-NN-FW module
REXROTH CSB01.1C-PL-ENS-NNN-NN-S-NN-FW module

REXROTH CSB01.1C-PL-ENS-NNN-NN-S-NN-FW module

REXROTH CSB01.1C-PL-ENS-NNN-NN-S-NN-FW module

The four channels on the CSB01.1C-PL-ENS-NNN-NN-S-NN-FW are configured at the factory and shipped as shown on the jumper and switch location diagram (Figure 4-12 on page 84). The jumpers provide the following configuration: RS-232 Jumpers G0 through G3 are jumpered 1 to 2; Jumpers F0 through F1 are jumpered 2 to 3. This jumper configuration allows for RS-232 transmission.

The CSB01.1C-PL-ENS-NNN-NN-S-NN-FW is configured with Hx 2 and Hx 3 installed. Hx 2 installed drives the internal TXC signal out to the connector (see Figure 4-5 on page 77). Hx 3 installed routes an external clock signal to the internal RXC (see Figure 4-4 on page 76). With Hx 2 installed, Hx 1 must be removed. With Hx 3 installed, Hx 4 must be removed.
