 IS215UCVEH2AE which is a component of the Mark VI Speedtronic control system from General Electric. This board functions as a VME control card, and the VME card rack is the standard rack for the Mark VI, available as a 13- or 21- slot rack. The IS215UCVEH2AE is a rectangular board with an attached front faceplate that includes an ethernet port, two COM ports, and a LAN port. It also has an opening for a mezzanine card. The board itself includes vertical pin connectors within the body of the board and right-angled pin connectors along the board’s edge. Additionally, the board has several integrated circuits, resistors, capacitors, chokes, and other components. There are several versions of this board available within the stock, so it is essential to order the correct board for the application [0].

According to [1], the IS215UCVEH2AE includes a front panel with three LED indicators located on the top of the circuit board. These are status indicators. In addition, the panel also includes a reset button, an opening for mezzanine cards, additional LEDs, and ports for LAN, SVGA, Ethernet, and other connections.

mentions that IS215UCVEH2AE is a VME Controller Card. The MK Vie I/O Packs contain two input/output network ports with a real-time clock and processor for synchronized sequence-of-events time-stamping and a data acquisition board.

The IS215UCVEH2A model is a dual-sided control designed for the LS2100 Series by General Electric Industrial Systems, according to [3]. The board is built with a front faceplate that includes three LED indicators as well as a reset button. Please note that the reset button is recessed to not be pressed accidentally. When being installed in the VMEbus rack for installation, it will go into the second slot. There are several capacitors, resistors, and chokes mounted on the board.

The IS215UCVEH2A board also includes a MicroSD card and two lithium batteries. This model can be used as a slave/master controller. On the model, there are built-in integrated circuits, and the standard use for these circuits is to hold any form of software information such as Turbine block library control functions for gas and steam products. The IS215UCVEH2A model is available in surplus at AX Control INCs warehouse.
