NI PXI-5922 module card

Product Details Introduction

NI PXI-5922 is a high-performance module card mainly used for high-precision data acquisition and signal analysis applications. The following is the product introduction of the module card:

High resolution data acquisition: The NI PXI-5922 module card has high-resolution data acquisition capabilities and supports 16 or 24 bit analog-to-digital converters (ADCs), enabling accurate signal measurement and acquisition.

Broadband wide signal acquisition: This module card has the capability of broadband wide signal acquisition, which can achieve high-speed signal acquisition and analysis. It supports high sampling rates and is suitable for measuring and analyzing high-frequency signals.

Multi channel configuration: The NI PXI-5922 module card supports multi channel configuration, and each channel can independently perform data collection and analysis. Multi channel configuration can achieve simultaneous acquisition and processing of multiple signal sources.

High precision clock synchronization: This module card has high-precision clock synchronization function, which can achieve precise synchronous collection between multiple channels. It supports external reference clocks and internal clocks, and suitable clock sources can be selected according to requirements.

Rich input and output interfaces: The NI PXI-5922 module card provides rich input and output interfaces, including analog input, digital input and output, clock input and output, etc. It can be connected to various sensors, signal sources, and devices to achieve flexible data acquisition and control.

Software support and programming interface: This module card is equipped with NI-DAQmx driver and LabVIEW software tools, providing an easy-to-use software interface and programming interface. Users can use these tools for configuration, control, and data processing to meet the needs of different applications.

PXI platform compatibility: The NI PXI-5922 module card adopts PXI interface, which is compatible with NI's PXI platform. It can be integrated with other PXI modules and devices to build high-performance testing and measurement systems.

Product image
