NI PXIe-4113 Control Pulse Card Module

Product Details Introduction

NI PXIe-4113 is a control pulse card module belonging to the PXIE series products of National Instruments (NI). The following is a product introduction about the NI PXIe-4113 control pulse card module:

Overview: The NI PXIe-4113 Control Pulse Card Module is a high-performance digital output module suitable for the PXIE platform. It can generate precise pulse and timing signals for controlling external devices and performing precise timing tasks.

Output channels: This module typically provides multiple independent digital output channels for generating pulse and timing signals. The number of channels can vary depending on specific models and configurations.

Output level range: NI PXIe-4113 control pulse card modules typically support standard digital output level ranges, such as TTL (Transformer Transformer Logic) or other common digital output level standards. It can adapt to different external devices and interface requirements.

Timing and triggering function: This module has flexible timing and triggering functions, which can achieve precise pulse generation and timing control. It supports multiple triggering modes and sources to meet the needs of different applications.

Configuration and monitoring: The NI PXIe-4113 control pulse card module has flexible configuration and monitoring functions, which can be set and monitored through corresponding software tools. Users can customize channel configuration, pulse width, frequency and other parameters to achieve diversified output control.

Software support: This module is usually equipped with corresponding software support, including NI-DAQmx driver and LabVIEW programming environment. These software tools provide rich functionality and development resources, making it easy for users to configure, control, and process data.

Application field: The NI PXIe-4113 control pulse card module is widely used in fields such as automation control, laboratory testing, and equipment activation. It can be used for various application scenarios such as precise pulse control, timing triggering, and timing activation.

Product image
