NI PXIe-5665 control motherboard card

Product Details Introduction

NI PXIe-5665 is a control motherboard card from National Instruments (NI) and belongs to the PXIE series of products. The following is a detailed introduction to the NI PXIe-5665 control motherboard card:

Overview: The NI PXIe-5665 control motherboard card is a high-performance RF and microwave signal analyzer module. It provides a wide frequency range and high-precision signal analysis capabilities, suitable for applications such as RF testing, communication system analysis, and radar system testing.

Frequency range: This module supports signal analysis over a wide frequency range, typically covering the frequency range from DC to high-frequency. The specific frequency range depends on the module model and configuration, which can meet the testing needs of different frequency signals.

High performance signal analysis: The NI PXIE-5665 control motherboard card has high-precision signal measurement and analysis capabilities. It provides a receiver with high dynamic range, low phase noise, and high sensitivity, which can be used for measuring and analyzing weak signals, high amplitude signals, and complex modulation signals.

Multiple measurement modes: This module supports multiple measurement modes, including spectrum analysis, power measurement, modulation analysis, time-domain analysis, etc. Users can choose appropriate measurement modes as needed to obtain the required signal parameters and features.

High speed data collection: The NI PXIe-5665 control motherboard card has the ability to collect and process high-speed data. It supports fast sampling rate and large capacity data storage, can be used for real-time acquisition and analysis of high-speed signals, and provides real-time data visualization and processing.

Software support: This module is equipped with corresponding software support, including the LabVIEW program development environment and related drivers. These software tools provide rich functions and development resources, making it convenient for users to conduct signal control, data analysis, and custom application development.

Application field: NI PXIe-5665 control motherboard cards are widely used in RF test system, communication system analysis, radar system test, radio spectrum monitoring and other fields. It can be used in application scenarios such as RF signal analysis, wireless communication device testing, and signal interference analysis.

Product image
