NI PXIe-2532B Analog Multiplex Switch Module

Product Details Introduction

NI PXIe-2532B is a high-speed analog multiplexer switch module from National Instruments (NI), belonging to the PXIE series of products. This module can be used for high-speed signal switching and routing applications, suitable for signal routing requirements in testing, measurement, and automation systems. The following is general product information about the NI PXIe-2532B module:

High bandwidth and low insertion loss: The PXIe-2532B module has the characteristics of high bandwidth and low insertion loss, enabling fast signal switching and transmission. It supports high-speed signal routing and is suitable for switching between high-frequency and broadband signals.

Multi channel and multi channel switch: This module supports multiple independent channels and multi channel switch functions, and can simultaneously switch and route multiple signals. Each channel has an independent switching circuit that enables independent signal routing.

Low circuit delay and high signal quality: The PXIe-2532B module has the characteristics of low circuit delay and high signal quality, which can maintain the accuracy and stability of the signal. It adopts high-speed switching circuits and precise signal transmission design to ensure fast switching and high-quality transmission of signals.

Multiple switching modes and triggering methods: The module supports multiple switching modes and triggering methods, such as single channel switching, multi-channel switching, trigger switching, etc. Users can choose suitable modes and triggering methods based on their specific needs.

Software support and development tools: The PXIe-2532B module can be used in conjunction with NI's software platforms and development tools, such as LabVIEW, NI-DAQmx, and NI-SystemLink. These tools provide rich functionality and easy-to-use interfaces, facilitating system configuration, signal routing, and control for users.

Product image
