NI PXI-2549 Digital Input/Output Module

Product Details Introduction

NI PXI-2549 is a digital input/output (DIO) module card from National Instruments (NI). It is part of the PXI (PCI eXtensions for Instrumentation) platform and provides reliable digital signal input and output functions, suitable for testing, measurement, and control applications.

The following are the main features and functions of the NI PXI-2549 digital input/output module:

Number of channels: The PXI-2549 module provides 64 independent digital input/output channels. Each channel can be used as input or output, with independent level converters and sampling circuits.

Input and output levels: This module supports TTL/CMOS level input and output. This makes it suitable for a wide range of digital signal applications and compatible with other digital devices and systems.

High speed performance: The PXI-2549 module has high-speed input/output capabilities and supports digital signal sampling and generation up to 50 MHz. This makes it suitable for high-speed data acquisition, digital communication, and fast control applications.

Hardware triggering function: This module supports hardware triggering and can synchronize with other PXI instruments and modules. This provides precise temporal correlation, allowing multiple modules to work together.

Software support: The NI PXI-2549 module is fully compatible with the software environment of National Instruments, such as LabVIEW and NI-DAQmx. This allows users to use common programming languages and tools for development, control, and data analysis.

PXI platform: The PXI-2549 module adopts a PXI bus interface and can be integrated with other PXI instruments and modules. This provides good scalability and interoperability, making it suitable for complex test and measurement systems

Product image
