NI PXIe-2575 High density matrix Switch Module

Product Details Introduction

NI PXIe-2575 is a high density matrix switch module of National Instruments (NI). It is a module based on the PXI Express (PXIE) platform that provides reliable signal switching function and is suitable for automatic testing and measurement systems.

The following are the main features and functions of NI PXIe-2575 high density matrix switch module:

Number of matrix channels: The PXIe-2575 module provides high-density matrix switches that can be selected from different channel configurations. It supports up to 256 single ended or 128 differential signal channels, meeting the multi-channel requirements in complex testing systems.

High speed performance: This module has high-speed signal switching capability and supports a bandwidth of up to 100 MHz. It is suitable for high-speed data acquisition, signal routing, and switching applications, ensuring the accuracy and reliability of signal transmission.

Flexible connectivity: The PXIe-2575 module has flexible connectivity options and can support multiple connection types, such as BNC, D-Sub, Spring Terminal, etc. This makes it suitable for various signal interfaces and connection requirements.

High density design: This module adopts a compact design, occupying less PXIE slot space. This makes it easier to achieve more signal switching and routing in limited space.

Software support: The NI PXIE-2575 module is fully compatible with the software environment of National Instruments, such as LabVIEW and NI-DAQmx. This allows users to use common programming languages and tools for development, control, and data analysis.

Product image
