NI PXIe-2515 High Bandwidth Matrix Switch Module

Product Details Introduction

The NI PXIe-2515 High Bandwidth Matrix Switch Module is a powerful signal switching solution. The following are the main product functional features:

High bandwidth performance: The PXIe-2515 module has high bandwidth signal switching capability, suitable for high-speed data acquisition and signal routing applications. It supports high-frequency and high-speed signal transmission to ensure the accuracy and reliability of signal transmission.

High density matrix switch: This module provides high density matrix switch capability, which can realize multi-channel signal switching and routing. It supports multiple input and output channels to meet the connection requirements of multiple signal sources in complex testing systems.

Low insertion loss: The PXIe-2515 module has low insertion loss characteristics to minimize signal attenuation and distortion. This is important for measurement and test applications that require high fidelity and accuracy.

Fast switching speed: This module has fast signal switching speed to reduce testing time and improve production efficiency. It can quickly switch signal paths to meet the requirements of fast testing and switching.

Flexible connection options: The PXIe-2515 module supports multiple connection interface options, such as BNC, D-Sub, Spring Terminal, etc. This enables users to choose appropriate connection methods based on specific needs and facilitate integration with other devices.

Highly scalable: This module adopts PXI Express (PXIE) interface, which has high scalability. Users can easily expand the testing system by combining multiple modules to meet more complex signal switching and routing requirements.

Software support: The NI PXIE-2515 module is compatible with the software environment of National Instruments, such as LabVIEW and NI-DAQmx. This enables users to use common programming languages and tools for development, control, and data analysis.

Product image
